Description
Features:
- Accurate parallelogram design enables table to travel in the same arc as the cutting circle, maintaining close uniform clearance between the table lip & cutterhead for safest operation regardless of cutting depth
- Spiral insert knife cutterhead with 30x12x1.5mm two sided knives. Spiral insert knife head runs quieter than a conventional straight knife head & provides a longer life of the cutting tools
- Table raising & lowering by convenient lever with locking knob to prevent accidental table movement
- Noise reduction table lips on infeed & outfeed tables for quiet operation
- Large center mounted fence with quick setting stops at 45o, 90 o and 135 o
- Smooth fence adjustment by rack & pinion
- Large diameter cutterhead is ground & balanced
- Spring loaded adjusting safety guard moves only when workpiece is being fed
- CSA magnetic switch
Specifications:
| Motor | 5HP |
| Max. cutting width | 12″ |
| Max. depth of cut | 3/4″ |
| Table size | 12″ x 84″ |
| Cutterhead RPM | 5000 RPM |
| Cutterhead inserts | 30x12x1.5mm (2) sided |
| Dust port | (1) 4″ |
