Description
FEATURES:
Exclusive Powermatic T-Square style Accu-Fence® maximizes accuracy and safety
The Accu-Fence has complete adjustability for aligning to blade and squaring to table
Sturdy cast iron table and trunnion assembly offers maximum rigidity for large work pieces
Positive locking cam with pressure adjustment
Oversized side plate can be used in the horizontal or vertical position
Solid steel resaw post for optimum rigidity
Blade tension release with electrical interlock prevents the bandsaw from starting when the blade is de-tensioned (patent pending)
Heavy duty upper wheel support and tracking mechanism for smooth operation
Solid cast iron upper and lower wheels create the momentum needed for heavy resaw
High end blade guides with tool less adjustment provide stability, increasing cut accuracy
Four sided blade guard for optimum protection
Foot brake with magnetic switch interrupt provides user with hands free stopping option
Magnetic switch protects the motor from harm due to potential electrical supply issues
Heavy-duty 5 horsepower motor provides power needed for all projects
460V operation requires an additional 460V magnetic switch – part PM1800B-043C
SPECIFICATIONS:
Cutting Capacity Width (In.)
20
Cutting Capacity Height (In.)
18
Blade Length (In.)
170
Minimum Saw Blade Width (In.)
1/4
Maximum Saw Blade Width (In.)
1-1/2
Blade Speed (SFPM)
2300/4400
Table Size (L x W) (In.)
24 x 27
Table Height from Floor (In.)
36
Table Tilt (Deg.)
10 Left, 45 Right
Miter Gauge Positive Stops
45, 90
Dust Port Outside Diameter (In.)
4
Dust Collection Minimum CFM Required (CFM)
600
Motor Power (HP)
5
Motor Phase
3
Motor Voltage (V.)
230/460
Prewired Voltage (V.)
230
Motor Current (Amps)
15/7.5
